Effortlessly switch between solar and DC inputs to keep your battery charged efficiently, all while enjoying the reliability and superior performance you expect.
- · Two charging options to ensure ultimate efficiency.
- · Supports LiFePO4, Gel, Flooded, and Sealed Lead Acid.
- · Comprehensive protections to safeguard the system.
- · Features lights and buttons for easy use and error alerts.
- · Complies with FCC, RoHS, CE, SAA; includes 2-year warranty.
Charging Data
System Voltage
12V-12V
Solar Input Voltage
10-30 VDC
Output Voltage
10-16 VDC
Alternator Input
Traditional Alternator: 13.2-16.0VDC
Smart Alternator (Euro 6): 12-16.0VDC
Smart Alternator (Euro 6): 12-16.0VDC
Maximum Output Current Rating
40A
Output Power
584W
Battery Types
AGM, Gel, Flooded, Lithium-iron Phosphate
Input Fuse Rating
60A
Output Fuse Rating
50A
Charging Efficiency
≥93%
Idle Power Consumption
10 mA
GENERAL DATA
Model
RBC40D1S
Grounding
Common Negative
Operating Temperature
'-4℉ -113℉ /-20 ℃ - 45℃
Storage Temperature
'-4℉ -140℉ /-20 ℃ - 60℃
Humidity
0%-95% RH
Cooling
Heat Sink
Enclosure Rating
IP31
Dimensions (LxWxH)
195 x 149 x 48 mm / 7.68 x 5.87 x 1.89 inch
Weight
1.2 kg /2.65 lb
Regulatory and Safety Specifications
FCC Path 15, Class B,CE,RoHS，SAA
